Main Machine: 650x 530x 2320mm

Hydraulic press: 1080x800x1100mm

Gross Weight,1450kg, Net Weight, 1400kg

Volume: Main Machine: 0.8m³

Hydraulic press: 0.95m³

Note: One free mould in required

Specifications of HT-2 Towel (T-shirt) Compressor

1. Main machine: iron frame, four universal wheel, 4 adjustable pedestals, steel operating platform sized of 520x640x80mm.

2. Hydraulic machine: Hydraulic vane pump and high pressure piston pump, dual motor, dual fuel tanks, two reversing valve

3. Oil tank: one upper and one lower oil tanks. the cylinder stroke for the lower is of 250mm, with pressure of 5-8 tons, the cylinder stroke for the upper is 400mm, with pressure of 30-45 tons

4. Machine supports 24hr work.

5. Machine total weight: 1.5 tons

6. Power: hydraulic vane pump is of 5.5 kW, high pressure piston pump is of 4 kW, Total Power is of 9.5 kW.  Power supply: 220V, 60Hz ,Three Phrase Four wires

7. Electronic parts: leakage protection, small relay, super time relay. Easy to operate and regulate.
